New Vehicles » Honda » CRF230F
Model Quick Search

$3,805.00

2008 Honda CRF230F
Request a Quote Financing Calculator Request a Brochure Financing Form
Click here to view full image.
Red
Request a Quote Financing Calculator Request a Brochure Financing Form
  • OEM Overview
  • Specifications
  • Compare Models
  • Current Promotions

Overview

 Print Brochure

Put in simple, moto-friendly terms, the CRF230F is a certified blast to ride. Just ask the countless riders, of all skill and experience levels, who've ever twisted its throttle and made easy work of the toughest trails. With its six-speed transmission, plush, long-travel suspension, electric starter, 34.1-inch seat height, and new fuel tank, it's the perfect—and perfectly sized—off-roader for adults and teenagers alike.

  • Rear Tire: 100/100-18
ENGINE
  • Engine Type: 223cc air-cooled single-cylinder four-stroke
  • Bore and Stroke: 65.5mm x 66.2mm
  • Compression Ratio: 9.0:1
  • Valve Train: SOHC; two-valve
  • Induction: 26mm piston-valve carburator
  • Ignition: CDI
DRIVE TRAIN
  • Transmission: Six-speed
  • Final Drive: #520 O-ring-sealed chain; 13T/50T
CHASSIS / SUSPENSION / BRAKES
  • Front Suspension: 37mm leading-axle Showa fork; 9.5-inch travel
  • Rear Suspension: Pro-Link Showa single-shock with spring-preload adjustability; 9.0-inch travel
  • Front Brake: Single 240mm disc
  • Rear Brake: Drum
  • Front Tire: 80/100-21
  • Rear Tire: 100/100-18
DIMENSIONS
  • Rake: 27.3 degrees
  • Trail: 112.0mm (4.4 inches)
  • Wheelbase: 54.1 inches
  • Seat Height: 34.1 inches
  • Ground Clearance: 11.7 inches
  • Dry Weight: TBD
  • Fuel Capacity: 1.9 gallons, including 0.4-gallon reserve
OTHER
  • Emissions: Meets current CARB and EPA standards. California version differs slightly due to emissions equipment.
  • Available Colors: Red
  • Model ID: CRF230F
FACTORY WARRANTY INFORMATION
  • 6 months: Coverage of defects in materials and workmanship

Specifications

Engine
Engine Type Single-cylinder four-stroke
Displacement 223 cc
Bore and Stroke 65.5 mm x 66.2 mm
Cooling Air-cooled
Compression Ratio 9.0:1
Fuel System 26 mm piston-valve carburator
Ignition CDI
Chassis
Front Suspension 37 mm leading-axle Showa fork; 9.5-in. travel
Front Brakes Single 240 mm disc
Front Tire 80/100-21
Rear Suspension Pro-Link Showa single-shock with spring-preload adjustability; 9.0-in. travel
Rear Brakes Drum
Rear Tire 100/100-18
Dimensions
Dry Weight TBD
Fuel Capacity 1.9 gal., including 0.4-gal. reserve
Wheelbase 54.1 in.
Ground Clearance 11.7 in.
Seat Height 34.1 in.
Trail 4.4 in. (112.0 mm)
Rake 27.3°
Transmission
Transmission Six-speed
Final Drive #520 O-ring-sealed chain; 13T/50T
General
Colors Red
Warranty 6 months: Coverage of defects in materials and workmanship

Compare Models

 Print








Year 2008
Manufacturer Honda
Model CRF230F
Style Off-Road
MSRP* $3,649.00
Chassis
Front Suspension 37 mm leading-axle Showa fork; 9.5-in. travel
Front Brakes Single 240 mm disc
Front Tire 80/100-21
Rear Suspension Pro-Link Showa single-shock with spring-preload adjustability; 9.0-in. travel
Rear Brakes Drum
Rear Tire 100/100-18
Dimensions
Dry Weight TBD
Fuel Capacity 1.9 gal., including 0.4-gal. reserve
Wheelbase 54.1 in.
Ground Clearance 11.7 in.
Seat Height 34.1 in.
Trail 4.4 in. (112.0 mm)
Rake 27.3°
Engine
Engine Type Single-cylinder four-stroke
Displacement 223 cc
Bore and Stroke 65.5 mm x 66.2 mm
Cooling Air-cooled
Compression Ratio 9.0:1
Fuel System 26 mm piston-valve carburator
Ignition CDI
General
Colors Red
Warranty 6 months: Coverage of defects in materials and workmanship
Transmission
Transmission Six-speed
Final Drive #520 O-ring-sealed chain; 13T/50T
